Signway networked multimedia player DS3528 employs the Rockchip quad core RK3528, having a strong capacity of multimedia processing and rich peripheral interfaces.
- 28nm-process made main chipset is high-performance and low-power
- HDMI/VGA/AV interfaces are provided for access of various displays with a resolution up to 4K
- Support LAN, WIFI and 3G networks., as well as standalone mode
- Work well with Signway GTV, ADPE and EzPoster content management system, fitting projects of any scale
- Capable of running multiple playlists as scheduled, with seamless transitions between videos and images, full-screen and split-screen displays.
- Supports background music playback while displaying HD images
- Supports display of scroll text, date, time, weather and LOGO
- With intelligent scheduling, contents can be played on a loop, at a specified time or idle hours, or as instant break-ins.
- Support network time and synchronization playback
- Contents can be updated remotely, or imported or read directly from a USB disk on site
- Player operations such as adjusting playback volume, changing display screen, reboot, sleep and wake can be completed remotely with just one click
- Playback and operation logs will be recorded and upload to the management system.
- Auto timed on/off in multiple periods enables unattended operation
- Both vertical and horizontal displays are supported
- Support split-screen zones for web access and touch interaction
- Support multi-touch screens
| Solution | RK3528 |
| CPU | Rockchip RK3528 Quad-core ARM Cortex-A53 2.0GHz |
| GPU | ARM Mali-450 MP |
| Memory | DDR3 2GB (4GB for option） |
| Storage | eMMC 32GB Note: Support TF expansion |
| Decoder | MPEG1, MPEG2, MPEG4, H.264, WMV, MKV, TS, flv, MP3, JPG, JPEG, BMP, PNG, GIF |
| Contents | Support Video/Image/Text/logo/Date/Time/Weekday/Weather/Background Image split-screen display |
| Playback | Contents are obtained via network and stored in local disk for playback on a loop, at a specified time.Contents are imported from a USB disk or stored in a USB disk |
| Content Management | CDMS(B/S architecture)-customized templates,idle-time/scheduled/looping playback,Muti-level audits,real-time monitoring, remote control, timel download, log statistics ADPE/EzPoster(C/S architecture)-program compilcation,schedule arragement export to a USB disk bi-directional encryption,timer on/off |
| LAN | 10/100M Ethernet |
| Wifi | 802.11bgn(BT optional) |
| Mobile |
|
| HDMI | 4K/60Hz |
| USB | USB type A *2（Internal) |
| Other | HDMI Output*1，3.5mm Output*1 |
| RTC | Time synchronization over network and time saving when power failure |
| Watch Dog | Hardware watch dog circuit included for auto recovery from failure |
| Input Power | DC 5.5x2.1mm, 12V |
| Work Temperature | 0℃~40℃ |
| Storage Temperature | -40℃-70℃ |
