Photo Booth Digital Signage CN-KAPB

  1. Mã sản phẩm: CN-KAPB
  2. Loại: TFT, Infrared, LCD Touch Screen
  3. Sử dụng: Trong nhà
  4. Kích thước: 43" 49" 55" 65" 75"
  5. Hệ điều hành: Window, Android
  6. Màn hình: Samsung, LG
  7. Độ phân giải: Full HD 1920x1080
  8. Độ sáng: 450 cd/m2
  9. Chế độ hiển thị toàn màn hình: 178 / 178
  10. Vỏ hợp kim nhôm chất lượng cao
  11. Tùy chỉnh chia màn hình thành nhiều nội dung khác nhau
  12. Lập thời gian tắt mở màn hình theo lịch
  13. Kết nối:  LAN/Wifi/3G, USB, VGA, HDMI

Thị trường sử dụng: Trung tâm mua sắm, cửa hàng bán lẻ, nhà hàng, khách sạn...

ID: CN-KAPB


With HD camera

Digital Signage With Photo Printer,Support that is, upload the printer to print, you can install the HD camera, that is, the camera that print now.

1080P HD Display

Support audio formats,1080P full HD loop play, advertising timing loop playing. Supports timing automatic power-play, automatic shutdown.

Supports Android System & Multiple Software Downloads

  • Support a variety of android devices remote control, edit content synchronization. Update, expand business opportunities
  • Support audio formats,1080P full HD loop play, advertising timing loop playing.
  • All your photograph you can be upload to social media.
  • Supports timing automatic power-play, automatic shutdown.

Support 3G/4G WiFi Network

Support 3G/4G wifi network to use , kid to study , playing games ,watching video ,surfing the internet.Also,support online picture printing.

Interactive Kiosk Display Back Design

Photo booth digital signage-Shell using low-carbon steel, galvanized sheet and other materials from strict processing .Streamlined and elegant design,support customized LOGO with led back light.

Product Details

About photo booth digital signage–All of our materials are subject to strict quality control to the procurement, we also designed to support custom products, the shell,we have the certificates are FCC, IP65, CE, ROHS.



CNTech là nhà phân phối màn hình quảng cáo uy tín, chất lượng tại thị trường Việt Nam. Với nhiều năm kinh nghiệm trong lĩnh vực cùng với đội ngũ nhân viên tư vấn, kỹ thuật được đào tạo và huấn luyện tốt chắc chắn sẽ mang đến cho bạn một sự trải nghiệm về phong cách phục vụ chuyên nghiệp và tận tình nhất.

CNTech Digital Signage Solution

Liên hệ với chúng tôi để nhận được hỗ trợ nhanh và tốt nhất: 0909 39 29 38

Email: sales@cntech.com.vn

Model

CN-KAPB PC Version

CN-KAPB Android Version









Screen

Panel Brand

Samsung & LG Full New 100% A+ Grade Brand Panel

Panel size

43"

Display area

523mm x 930mm

Display ratio

16:9

Resolution

1080*1920

Viewing angle

178°/178°(H/V)

Color

16.7M

Backlits

LED

Brightness

450 cd/m2

Contrast

5000:1







OS System

Standard:main board:G61 CPU:G620

CPU: 8 core Cortex-A15, 1.5GHZ

RAM:KINSTON2GB  Hard disk:500GB

DDR: :DDR3 4G

Superior:main board:G61 CPU:I3 2120

Exteral ROM Support up to 32G bytes sd card

RAM:KINSTON 4GB  Hard disk:500GB

ROM NAND FLASH: 8G

Operation

Windows 7

Android 4.2(can be upgraded)

Connection to network

RJ45, 3G, WIFI (optional)

RJ45 ,3G,WIFI (optional)





Touch Screen

system



Touch screen

Infrared touch screen

(touch foil, capacitive)



Infrared touch screen

(touch foil, capacitive)



Touch ways

finger,touch pen

finger,touch pen

Touch dots

1/2/4/6 dots (optional)

2 dots

Durability

More than 50 million touch

More than 50 million touch



Power

Power

140W

120W

Voltage

AC100-240V 50/60HZ

AC100-240V 50/60HZ

Stability

good

good







Instructions

Interface

VGA/HDMI/USB

HDMI/USB/SD

Working

temperature

-5°C-75°C

-5°C-75°C

Material

Aluminum alloy,tempered glass

Aluminum alloy,tempered glass

Surface

Spraying,frosted aluminum

Spraying,frosted aluminum

Size

Undetermined

Undetermined

Weight

Undetermined

Undetermined



Body

Shell

Galvanized   steel sheet. Thickness:1.0-1.5mm.

Color

Black , white , silver or customized colors

Packing

By carton with foam inside & woonden



Optional Functions

Anti-dazzle

3G  Capability

Human sensor

Fan, temperature and light sensor

Tổng quan sản phẩm:

  • Định dạng Hỗ trợ: Định dạng ảnh, JPEG, BMP, PNG. Định dạng video, MPG, MPEG, DAT, MP4, AVI, VOB, TRP, TP, M2TS, TS, RM, RMVB, MKV, DIVX, MOTONJPEG, ASF, WMV, FLV. Định dạng âm nhạc, MP3, AAC-LC, WMA.
  • Tự động và chạy chu kỳ khi bật nguồn, phát theo tên dữ liệu hoặc danh sách phát.
  • Có thể thiết lập 5 nhóm bật / tắt tự động với âm lượng. Bộ đếm giờ hàng ngày và hàng tuần bật / tắt.
  • Chế độ hiển thị đa thời gian.
  • Hỗ trợ hiển thị hình ảnh thời gian, và các chế độ trình chiếu khác nhau có thể được thiết lập.
  • Hỗ trợ ảnh / nhạc / ảnh / video / nhạc / tất cả / danh sách phát.
  • Hỗ trợ danh sách nhạc: chơi ảnh / video / nhạc và phụ đề trong một khoảng thời gian xác định.
  • Hỗ trợ một roll.txt có thể bật hoặc tắt, nhiều màu sắc marguee và màu sắc trở lại.
  • Hỗ trợ ảnh / video tất cả lặp lại, lặp lại một lần, hoặc không lặp lại.
  • Hỗ trợ chức năng tiếp tục điện.
  • Hỗ trợ USB tốc độ cao cập nhật thông tin, hỗ trợ nâng cấp chức năng USB.
  • Hiệu ứng điều chỉnh: độ sáng, độ tương phản, màu sắc, độ sắc nét, đèn nền, giảm tiếng ồn, chế độ video.
  • Hỗ trợ kiểm tra dữ liệu của hình ảnh hoặc video.
  • AD chèn: 1-60 phút, lên đến 9 AD có thể được chèn.
  • Chức năng mới: Có thể thiết lập phân chia màn hình từ 1 đến 10 phần cho phát sóng video và hình ảnh, miễn phí để thiết lập các phần. (yêu cầu chức năng này nên được thông báo khi đặt hàng).
